RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.02
Function Description
you are using the internal RTA to check the room tune, then you would select
Mic.
Note: When the Input field is LineIn, the RTA selects the input channel. The
controls for EQ, bass, treble, and trim represent what is applied to input channel
and their effects will not show up on the RTA display.
When the input field is set to Mic, the RTA selects the Mic input which will show
the effects of the EQ settings as well as the room. Channel tuning should be
done in this input or with an external RTA.
RTA Options
See 4.4.3.2 RTA Options, p
age 58.
Level/Bass/Treble
adjustments
Touch the Level, Bass, or Treble bar, which becomes highlighted, then adjust it
up or down using the Volume Control knob. These adjustments apply to the
same channel as the EQ ch, as shown by the text on the left side of the third
octave adjustments.
 Level – Adjusts the output signal level from -20dB to +10dB in increments of
0.5dB.
 Bass – Bass adjustment from -6dB to +6dB in increments of 0.1 dB. The
corner frequency for the bass control is shown at left of the adjustment bar.
 Treble – Treble adjustment from -6dB to +6dB in increments of 0.1 dB. The
corner frequency for the treble control is shown at left of the adjustment bar.
 Corner Frequency adjustments – Touch the corner frequency box for treble
or bass and adjust using the Volume Control knob. The corner frequency
for bass can be set from 50Hz to 300Hz. The corner frequency for the treble
can be set from 1.5kHz to 12kHz. The corner frequency cannot be set for
individual channels—the setting affects all channels in the current EQ set.
Levels
See 4.4.6 Audio Levels, page 62.
Copy EQ
See 4.4.5 Copy/Clear EQ, page 61.
