Maintenance

DeLaval voluntary milking system VMS

94897201.pdf2007-12-18

FG

Handle

Barrel

2. Insert the handle of the assembly tool

into the barrel of the liner.

FG

3. Insert the liner into the teatcup.

FG

4. Fit the liner head onto the teatcup.

126(198)
