Troubleshooting
DeLaval voluntary milking system VMS
94897201.pdf2007-12-18
M m Alarm text Type Meaning ActionM m Alarm text Type Meaning Action
1 111 Cow not
identified
Deviation The cow has not been identified
within the preset time and will be
released.
If identification fails for all cows, contact
service engineer.
Service engineer only: The time the system
tries to identify a cow can be changed in the
management software (VMS Config).
If the cow(s) for which the identification
failed are known, check the transponder(s):
Remove the transponder from the cow,
press “Accept cow” on the touch screen,
activate the photocell until the entrance
gate is closed, then put the transponder
close to the transponder. The cow number
associated with transponder should now be
shown on the touch screen.
If this alarm appears several times a week,
make sure that the transponder collars are
loose enough for the transponders to hang
vertically from the neck of the cows.
Otherwise, the transponder reader might
have difficulty in reading the transponder
number.
1 111 Cow not
identified
Deviation The cow has not been identified
within the preset time and will be
released.
If identification fails for all cows, contact
service engineer.
Service engineer only: The time the system
tries to identify a cow can be changed in the
management software (VMS Config).
If the cow(s) for which the identification
failed are known, check the transponder(s):
Remove the transponder from the cow,
press “Accept cow” on the touch screen,
activate the photocell until the entrance
gate is closed, then put the transponder
close to the transponder. The cow number
associated with transponder should now be
shown on the touch screen.
If this alarm appears several times a week,
make sure that the transponder collars are
loose enough for the transponders to hang
vertically from the neck of the cows.
Otherwise, the transponder reader might
have difficulty in reading the transponder
number.
1 112 Unexpected
high yield
Deviation More milk (50%) than expected
has been obtained from a quarter.
Check the corresponding air-inlet is not
clogged. If the problem persists, contact
service engineer.
1 112 Unexpected
high yield
Deviation More milk (50%) than expected
has been obtained from a quarter.
Check the corresponding air-inlet is not
clogged. If the problem persists, contact
service engineer.
1 114 Mumgr
disconnected
Stop alarm The main program in the milking
station is deactivated.
Restart the milking station. If the problem
persists, contact service engineer.
1 114 Mumgr
disconnected
Stop alarm The main program in the milking
station is deactivated.
Restart the milking station. If the problem
persists, contact service engineer.
1 115 Unexpected
low yield
Deviation Less than 40% of the expected
yield has been obtained from a
quarter.
Check the cow.1 115 Unexpected
low yield
Deviation Less than 40% of the expected
yield has been obtained from a
quarter.
Check the cow.
1 117 High MS
temperature(-
...)
User
notification
Temperature in the system is
above 60 degrees centigrade.The
alarm will call the farmer but
system will remain in auto mode.
Temperature must go below 60
and up again to trigg a new alarm.
Turn on or increase the flow of cooling air to
the electrical cubicle.
1 117 High MS
temperature(-
...)
User
notification
Temperature in the system is
above 60 degrees centigrade.The
alarm will call the farmer but
system will remain in auto mode.
Temperature must go below 60
and up again to trigg a new alarm.
Turn on or increase the flow of cooling air to
the electrical cubicle.
1 119 Not cleaned
after divert
Stop alarm A rinse or cleaning should have
been carried out after the last
milking, but was not. The selected
milk type for the cow is probably
"Divert milk" after wich normally
should follow a cleaning
procedure. (This milk type is used,
for example, when a cow receives
some kind of medical treatment.)
Start a rinse or cleaning manually.1 119 Not cleaned
after divert
Stop alarm A rinse or cleaning should have
been carried out after the last
milking, but was not. The selected
milk type for the cow is probably
"Divert milk" after wich normally
should follow a cleaning
procedure. (This milk type is used,
for example, when a cow receives
some kind of medical treatment.)
Start a rinse or cleaning manually.
1 120 Autocalibrati-
on fails
status ...
Deviation Autocalibration of the robot has
failed.
Additional information: 20 =
Problem with Balance or PRBS
calibration. 21 = Problem with
performance. 30 = Calibration
cancelled by operator. (Previous
calibration data will be used.)
No action is necessary if the robot performs
well. Inform service engineer if the robot is
not working well.
1 120 Autocalibrati-
on fails
status ...
Deviation Autocalibration of the robot has
failed.
Additional information: 20 =
Problem with Balance or PRBS
calibration. 21 = Problem with
performance. 30 = Calibration
cancelled by operator. (Previous
calibration data will be used.)
No action is necessary if the robot performs
well. Inform service engineer if the robot is
not working well.
1 121 Guardmaster
block MS
User
notification
US market only. Guardmaster has
been activated and is blocking
movement of robot arm and
magazine.
Clear blocking by entering pin code at
Guardmaster. This will allow normal
operation of milksing station
1 121 Guardmaster
block MS
User
notification
US market only. Guardmaster has
been activated and is blocking
movement of robot arm and
magazine.
Clear blocking by entering pin code at
Guardmaster. This will allow normal
operation of milksing station
1 122 Guardmaster
allow MS
Status
message
US market only. Guardmaster has
granted normal operation of
milking station.
None1 122 Guardmaster
allow MS
Status
message
US market only. Guardmaster has
granted normal operation of
milking station.
None
158(198)
