Troubleshooting
DeLaval voluntary milking system VMS
94897201.pdf2007-12-18
M m Alarm text Type Meaning ActionM m Alarm text Type Meaning Action
5 108 Bad system
vacuum...
kPa ref... kPa
May give
stop call
after
recovery
The system vacuum to the milking
station is deviating too much from
the setpoint values (set in PC).
Checked under milking only.
Check the system vacuum or calibrate the
sensors.
Check setpoint value in PC. If sensor is
broken, calibrate so it shows correct
vacuum. If setpoint is 0 the system will not
check the vacuum level.
5 108 Bad system
vacuum...
kPa ref... kPa
May give
stop call
after
recovery
The system vacuum to the milking
station is deviating too much from
the setpoint values (set in PC).
Checked under milking only.
Check the system vacuum or calibrate the
sensors.
Check setpoint value in PC. If sensor is
broken, calibrate so it shows correct
vacuum. If setpoint is 0 the system will not
check the vacuum level.
Service engineer only:
- Start the management software and check
that "System vacuum level" is set to 44 kPa.
- If the problem presist, calibrate the
vacuum sensor. Do as follows:
- Attach a calibrated meter to the outlet on
the control box in the lower beam.
- On the touch screen, press "VMS" > "Test
VMS".
- On the keypad that appears on the
screen, type "VMS".
- Press "Service Test".
- Press "Lower beam" (for "Lower beam 2")
and scroll until you find "Sense vacuum
level".
- Press the "Sense vacuum level" button.
- Press "Calibrate" and follow the
instructions on the screen.
- When the calibration is complete, restart
the milking station.
Service engineer only:
- Start the management software and check
that "System vacuum level" is set to 44 kPa.
- If the problem presist, calibrate the
vacuum sensor. Do as follows:
- Attach a calibrated meter to the outlet on
the control box in the lower beam.
- On the touch screen, press "VMS" > "Test
VMS".
- On the keypad that appears on the
screen, type "VMS".
- Press "Service Test".
- Press "Lower beam" (for "Lower beam 2")
and scroll until you find "Sense vacuum
level".
- Press the "Sense vacuum level" button.
- Press "Calibrate" and follow the
instructions on the screen.
- When the calibration is complete, restart
the milking station.
5 109 Good milk
valve in
wrong
position
Stop alarm The valve for "good milk"
(consumable milk) is not in the
requested position.
Check the function of the sensor and its
LEDs (Light Emitting Diode).
5 109 Good milk
valve in
wrong
position
Stop alarm The valve for "good milk"
(consumable milk) is not in the
requested position.
Check the function of the sensor and its
LEDs (Light Emitting Diode).
5 110 Dump milk
valve in
wrong
position
Stop alarm The valve for "bad milk"
(non-consumable milk) is not in the
requested position. "Good milk"
(consumable milk) might be
pumped to drain.
Check the function and the sensor and its
LEDs (Light Emitting Diode).
5 110 Dump milk
valve in
wrong
position
Stop alarm The valve for "bad milk"
(non-consumable milk) is not in the
requested position. "Good milk"
(consumable milk) might be
pumped to drain.
Check the function and the sensor and its
LEDs (Light Emitting Diode).
5 112 Endunit
indicates
empty Error
Stop alarm Problems when emptying the
receiver (end unit). System has
milked more than 2 kg and is about
to empty the receiver, but the level
sensors inform the system that the
receiver is already empty.
Check the receiver and its level sensors
(endunit level).
5 112 Endunit
indicates
empty Error
Stop alarm Problems when emptying the
receiver (end unit). System has
milked more than 2 kg and is about
to empty the receiver, but the level
sensors inform the system that the
receiver is already empty.
Check the receiver and its level sensors
(endunit level).
5 113 Timout
emptying
endunit -
check filter
valve
Stop alarm The level sensors are indicating
that the receiver is not empty even
though the milk pump has been
running for 60 seconds.
In particular, make sure that the valve at the
milk filter is open. Check the level sensors
(endunit level).
Check the milk pump and the motor
overload protection. Check if any valves are
closed that should be open.
5 113 Timout
emptying
endunit -
check filter
valve
Stop alarm The level sensors are indicating
that the receiver is not empty even
though the milk pump has been
running for 60 seconds.
In particular, make sure that the valve at the
milk filter is open. Check the level sensors
(endunit level).
Check the milk pump and the motor
overload protection. Check if any valves are
closed that should be open.
5 114 Teatcleaner
tank full
Deviation A sensor in the wastewater tank
(teatcleaner tank) indicates that
the tank is full. The tank should not
be full during normal operation.
The system tries to empty the tank.
Check the wastewater tank (teatcleaner
tank). If the problem persists, contact
service engineer.
5 114 Teatcleaner
tank full
Deviation A sensor in the wastewater tank
(teatcleaner tank) indicates that
the tank is full. The tank should not
be full during normal operation.
The system tries to empty the tank.
Check the wastewater tank (teatcleaner
tank). If the problem persists, contact
service engineer.
5 115 Milk diverted Deviation Milk was diverted. None required.5 115 Milk diverted Deviation Milk was diverted. None required.
5 116 Cleaning
aborted
Deviation A cleaning process has been
manually cancelled.
A cleaning process should not be
interrupted. Restart the cleaning process to
prevent bacteria or cleaning detergent from
contaminating the milk.
5 116 Cleaning
aborted
Deviation A cleaning process has been
manually cancelled.
A cleaning process should not be
interrupted. Restart the cleaning process to
prevent bacteria or cleaning detergent from
contaminating the milk.
