Group 5: Multi-step Speeds Parameters
05.00 1st Step Speed Frequency Unit: 0.01
05.01 2nd Step Speed Frequency Unit: 0.01
05.02 3rd Step Speed Frequency Unit: 0.01
05.03 4th Step Speed Frequency Unit: 0.01
05.04 5th Step Speed Frequency Unit: 0.01
05.05 6th Step Speed Frequency Unit: 0.01
05.06 7th Step Speed Frequency Unit: 0.01
05.07 8th Step Speed Frequency Unit: 0.01
05.08 9th Step Speed Frequency Unit: 0.01
05.09 10th Step Speed Frequency Unit: 0.01
05.10 11th Step Speed Frequency Unit: 0.01
05.11 12th Step Speed Frequency Unit: 0.01
05.12 13th Step Speed Frequency Unit: 0.01
05.13 14th Step Speed Frequency Unit: 0.01
05.14 15th Step Speed Frequency Unit: 0.01
Settings 0.00 to 600.0Hz Factory Setting: 0.00
The Multi-function Input Terminals (refer to setting 1~4 of Pr.04.05 to 04.08) are used to select
one of the AC motor drive Multi-step speeds(max. 15 speeds). The speeds (frequencies) are
determined by Pr.05.00 to 05.14 as shown in the following.
The operation time of multi-step speeds can be set by PLC program.
The run/stop command can be controlled by the external terminal/digital
keypad/communication via Pr.02.01.
Each one of multi-step speeds can be set within 0.0~600.0Hz during operation.
These parameters can be applied in small machinery, food processing machinery, washing
equipment to control the operation procedure. It can be used instead of traditional circuit, such
as relay, switch or counter.
Explanation for the timing diagram for multi-step speeds and external terminals
The Related parameter settings are:
1. Pr.05.00~05.14: setting multi-step speeds (to set the frequency of each step speed)
2. Pr.04.05~04.08: setting multi-function input terminals (multi-step speed 1~4)
3. The repeat operation setting of 1st-15th step speed frequency: can use PLC program to
control. Please refer to Appendix D How to use PLC function for details.
