Delta VFD-E

Chapter 4 Parameters|
4-186 Revision Jan. 2009, 06EE, SW--PW V1.12/CTL V2.12
Parameter Explanation Settings
Factory
Setting
Custome
r
09.24 DS402 Protocol
0: Disable (By Delta rule)
1: Enable (By DS402)
1
Group 11 Parameters for Extension Card
Parameter Explanation Settings
Factory
Setting
Customer
0: No function 0
1: Multi-Step speed command 1
11.06
Multi-function Input
Terminal (MI7)
2: Multi-Step speed command 2
3: Multi-Step speed command 3 0
4: Multi-Step speed command 4
11.07
Multi-function Input
Terminal (MI8)
5: External reset
6: Accel/Decel inhibit 0
7: Accel/Decel time selection command
11.08
Multi-function Input
Terminal (MI9)
8: Jog Operation
9: External base block 0
10: Up: Increment master frequency
11.09
Multi-function Input
Terminal (MI10)
11: Down: Decrement master frequency
12: Counter Trigger Signal 0
13: Counter reset
14: E.F. External Fault Input
11.10
Multi-function Input
Terminal (MI11)
15: PID function disabled
16: Output shutoff stop 0
17: Parameter lock enable
18: Operation command selection (external
terminals)
19: Operation command selection (keypad)
20: Operation command selection
(communication)
21: FWD/REV command
22: Source of second frequency command
11.11 Multi-function Input
Terminal (MI12)
23: Quick Stop (Only for VFD*E*C models)
