User's Guide
- 119 -
3. To continue using a computer for Internet access, connect the computer to the DSL HPN port on the
DSL filter.
4. To connect a telephone to the printer, remove any installed adapter plug from the
port of the
printer, and then connect the telephone to the port.
Scenario 3: VoIP telephone service
To connect:
1. Connect one end of the telephone cable that came with the printer to the
port of the printer.
2. Connect the other end of the cable to the port labeled Phone Line 1 or Phone Port on the VoIP
adapter.
Note: The port labeled Phone Line 2 or Fax Port is not always active. VoIP providers may charge
additional cost for activation of the second phone port.
3. Connect the telephone to the
port of the printer.
Tips for this setup:
• To make sure that the phone port on the VoIP adapter is active, plug an analog telephone into the
phone port, and then listen for a dial tone. If you hear a dial tone, then the port is active.
