DigiDesign D-show User Manual

D-Show Guide184
D-Show Sidecar Mechanical Specifications
Maximum Height (front) 3.2 inches (81 mm)
Maximum Height (rear) 13.7 inches (347 mm)
Maximum Width (with endcaps) 28.7 inches (729 mm)
Maximum Width (without endcaps) 26.5 inches (673 mm)
Maximum Depth 34.8 inches (884 mm)
Weight 73 lbs (33.2 kg)
Power Requirements 90–260 VAC, 50–60 Hz, 120 W
Console Link (CAN bus) Connectors (2) XLR3-M (1 male, 1 female)
Console Link Cable Type 110-ohm (digital) cable
Max Console Link Cable Length Single cable: 25 ft (7.6 m); Total length: 75 ft (22.9 m)
Sidecar dimensions
34.8"
(884 mm)
28.7"
(729 mm)
13.7"
(347 mm)
34.8"
(884 mm)
3.2"
(81 mm)
