Chapter 24: Mechanical Specifications 185
D-Show Main Unit plus Sidecar Mechanical Specifications
Maximum Height (front) 3.2 inches (81 mm)
Maximum Height (rear) 13.7 inches (347 mm)
Maximum Width (with endcaps) 78.3 inches (1988 mm)
Maximum Width (without endcaps) 76.1 inches (1933 mm)
Maximum Depth 35.5 inches (895 mm)
Weight 194 lbs (88 kg)
Power Requirements (Main Unit) 90–260 VAC, 50–60 Hz, 160 W
Power Requirements (Sidecar) 90–260 VAC, 50–60 Hz, 120 W
Console Link Cable Type 110-ohm (digital) cable
Max Console Link Cable Length Single cable: 25 ft (7.6 m); Total length: 75 ft (22.9 m)
Main Unit plus Sidecar dimensions
35.5"
(895 mm)
78.3"
(1988 mm)
