LEFT FRONT DOOR SPEAKER-3WAY
CAV CIRCUIT FUNCTION
1 X87 18LG/VT (NORMAL BUILD) AMPLIFIED LEFT DOOR SPEAKER (+)
2 X87 18LG/VT (EARLY BUILD) AMPLIFIED LEFT DOOR SPEAKER (+)
3 X85 18LG/BK AMPLIFIED LEFT DOOR SPEAKER (-)
LEFT FRONT PARK/TURN SIGNAL LAMP (DODGE)-3WAY
CAV CIRCUIT FUNCTION
1 Z1 18BK GROUND
2 L7 18BK/YL PARK LAMP RELAY OUTPUT
3 L61 18LG LEFT TURN SIGNAL
LEFT FRONT PARK/TURN SIGNAL LAMP (EXCEPT DODGE) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 L61 18LG LEFT TURN SIGNAL
2 L7 18BK/YL PARK LAMP RELAY OUTPUT
3 Z1 18BK GROUND
LEFT FRONT POSITION LAMP-2WAY
CAV CIRCUIT FUNCTION
1 L7 20BK/YL PARK LAMP RELAY OUTPUT
2 Z1 20BK GROUND
LEFT FRONT SIDE MARKER LAMP (CONCORDE/LTD) - NATURAL 2 WAY
CAV CIRCUIT FUNCTION
1 L7 20BK/YL PARK LAMP RELAY OUTPUT
2 L61 20LG LEFT TURN SIGNAL
LH 8W-80 CONNECTOR PIN-OUTS 8W - 80 - 61
