(4) Remove transaxle oil filter (Fig. 15).
(5) Remove seven valve body-to-case bolts (Fig.
16).
CAUTION: Do not handle the valve body by the
manual shaft. Damage could result.
(6) Remove valve body from transaxle (Fig. 17).
NOTE: For valve body recondition procedure, (Refer
to 21 - TRANSMISSION/TRANSAXLE/AUTOMATIC -
42LE/VALVE BODY - DISASSEMBLY).
(7) Remove underdrive accumulator and spring
(Fig. 18) (Fig. 20).
Fig. 15 Remove Transaxle Oil Filter
1 - TRANSAXLE FILTER
2 - FILTER RETAINING CLIPS
Fig. 16 Remove Valve Body Bolts (17)
1 - EXTENSION
2 - SOCKET
3 - VALVE BODY
Fig. 17 Remove Valve Body From Transaxle
1 - VALVE BODY
Fig. 18 Remove Underdrive Accumulator and
Springs
1 - ACCUMULATOR PISTON (UNDERDRIVE)
2 - RETURN SPRINGS
3 - SEAL RING
4 - SEAL RING
LH TRANSAXLE 21 - 13
42LE AUTOMATIC TRANSAXLE (Continued)
