(53) Drive out anchor shaft using suitable punch
(Fig. 71).
(54) Remove guide bracket pivot shaft (Fig. 72).
Inspect all components (Fig. 73) for wear and replace
if necessary.
(55) Remove low/reverse clutch piston (Fig. 74).
Fig. 71 Anchor Shaft Removal
1 - PIN PUNCH
2 - GUIDE BRACKET ASSEMBLY
Fig. 72 Remove Guide Bracket Pivot Shaft
1 - PIVOT PIN
2 - GUIDE BRACKET ASSEMBLY
Fig. 73 Guide Bracket Disassembled
1 - ANTIRATCHET SPRING
2 - GUIDE BRACKET
3 - SPLIT SLEEVE
4 - SPACER
5-PAWL
6 - STEPPED SPACER
Fig. 74 Remove Low/Reverse Clutch Piston
1 - LOW/REVERSE CLUTCH PISTON
2 - D-RING SEAL
3 - D-RING SEAL
LH TRANSAXLE 21 - 27
42LE AUTOMATIC TRANSAXLE (Continued)
