Fig. 93 Special Tool Installed
1 - SPECIAL TOOL 6618–A
Fig. 94 Shim Installation
1 - SHIM
2 - OUTPUT SHAFT
Fig. 95 Press Shaft Into Case
1 - SPECIAL TOOL C-4171 AND C-4171–2
2 - SPECIAL TOOL MD-998911
Fig. 96 Checking Turning Torque
1 - TORQUE WRENCH
2 - SPECIAL TOOL 6498
3 - OUTPUT SHAFT NUT
LH TRANSAXLE 21 - 33
42LE AUTOMATIC TRANSAXLE (Continued)
