(9) Install separator plate to transfer plate (Fig.
440).
(10) Install the two separator plate-to-transfer
plate screws (Fig. 441).
(11) Install the transfer plate to the valve body
(Fig. 442).
(12) Install the transfer plate-to-valve body screws
(Fig. 443)and torque to 5 N·m (45 in. lbs.).
Fig. 440 Install Separator Plate to Transfer Plate
1 - SEPARATOR PLATE
2 - TRANSFER PLATE
Fig. 441 Install Separator Plate-to-Transfer Plate
Screws
1 - SEPARATOR PLATE
2 - SCREW (2)
3 - TRANSFER PLATE
Fig. 442 Install Transfer Plate to Valve Body
1 - TRANSFER PLATE
2 - VALVE BODY
Fig. 443 Install Transfer Plate-to-Valve Body Screws
1 - SCREW (24)
2 - TRANSFER PLATE
21 - 166 TRANSAXLE LH
VALVE BODY (Continued)
