Setting Name Description
X (mm) Set the horizontal position of the object in the template.
Y (mm) Set the vertical position of the object in the template.
Width (mm) Set the width of the object.
Height (mm) Set the height of the object.
Scale mode Set the scale mode of the object:
• Scale - The width and height of the object can be set•
independently.
• Auto size - The width and height of the object is•
controlled by the font size.
Angle Rotate the object.
Lock Lock the object to prevent it from being edited.
Visible Make the object printable or not printable.
Font family Set the font type.
Size (pt) Set the font size.
Style Choose:
• Bold•
•
Italic
•
• Underlined.•
Text align If the object has more than 1 line, set the alignment:
• Left•
•
Center
•
• Right.•
Remove blank line Remove blank lines from the object.
Remove leading space Remove leading spaces from the object.
12.
In the Database tab, use the settings listed below to change database object settings:12.
Name Description
Remove source
Note This setting is only visible, if a database source
is selected.
Disconnect the object from the current database source. This
lets a new database source be selected.
Load database Load a database file from a connected USB memory device.
Load VDC Load and setup a variable database connection source.
Source This is a list of items that are available to add to the database
object. To add an item to the database object, use the arrow
icons to move it to the Destination list.
Destination This is a list of items that have been added to the database
object. To remove an item from the database object, use the
arrow icons to move it to the Source list.
OPERATION
120 EPT077343 EN - Issue 1 - 11 November 2022
