PSS5000/TEMA/803046/05 75 of 152

PSS 5000 – Technical Manual

7 Reset (Menu 4)

3. Press to select the SUPER M RESET? menu.

4. Press and hold OK + for 10 seconds.

The system performs a Super Master Reset and the display shows

...SUPER

MASTER RESET
