DMM-0200 Product User Guide
159 Swanson Road  Boxborough, MA 01719  Tel: 508-475-3400  Email: sales@dovermotion.com
12.86 cm
Figure 1 DMM-0200 Dimensions
24.06 cm 20.05 cm
Site Requirements
Requirements for Receiving and Setup
Receiving
When you receive your DMM-0200, do the following:
1. Inspect the package for damage.
Caution: If you suspect damage, take pictures of the location where you suspect there is
damage. A representative of the shipping carrier may need to be present during the unpacking
process for insurance purposes.
Setup
Select a location where you want the DMM-0200 to be unpacked and installed. Please ensure the following parameters
are met:
Table 1 Weights and Measurements
Specification
DMM-0200
Weight
2.24 Kg (approx. 4.95 lbs)
Dimensions (maximum):
Width
24.06 cm (approx. 9.47 inches)
Depth
20.05 cm (approx. 8.08 inches)
Height
12.86 cm (approx. 5.06 inches)
