Page 37 of 112
DMM-0200 Product User Guide
159 Swanson Road
Boxborough, MA 01719
Tel: 508-475-3400
Email: sales@dovermotion.com
Connecting to the DMM-0200
Installing the Motor and Encoder Cables
Caution: Before plugging in any motor and encoder cables, verify the mechanical operation of
your Dover Motion stage. Verify that the stage moves freely as intended and that there is no
potential for damage or personal injury.
Note: If you have any questions regarding the mechanical operation of your stage or the connecting
to the DMM-0200, please call the Dover Motion customer service department:
Phone: 508-475-3400
Email:
sales@dovermotion.com
Plug in the motor and encoder cables to the appropriate rear panel connectors. Plug in your motor and encoder
connections before plugging in the power cable.
Installing the I/O Cables
Caution: Before plugging in the I/O cables, verify that your I/O devices operate as intended and
there is no potential for damage or personal injury.
Plug in the I/O cables to the appropriate rear panel connectors. Plug in your I/O connections before plugging in the
power cable.
Installing the Power Cord and Communications Cables
The DMM-0200 comes with a 2.4 meter (approx. 8 foot) power cord. You must supply the USB 2.0 cable.
To install the power cord, insert the female connector on the power cord into the male receptacle on the rear of the
system enclosure. The USB 2.0 cable plugs into the USB connector on the rear panel. See the Rear Panel section for
the locations of these connectors.
Note: After plugging in the power cord, the DMM-0200 is ready to be turned on.
