Rear Panel Connector Pinouts
Pinouts – Serial Communications (J4-SERIAL X, J21-SERIAL Y)
Pin Number
Function
Description
DE-9-M Connector
1
N/C
5
9
6
1
2
RX
Receive data
3
TX
Transmit data
4
N/C
5
GND
Ground
6
N/C
7
N/C
8
N/C
9
N/C
Table 7 Pinouts – Serial Communications
Note: The two serial connectors on the rear panel are used for setting up the individual drivers
for each axis of motion. This is already done at Dover Motion.
Under normal circumstances, the user should not need to communicate to the individual drivers
and therefore should not need to connect to these four serial ports.
Should you need to communicate to the individual drivers, please contact the Dover Motion
Service Department for assistance.
Pinouts – USB Communication
Pin Number
Function
Description
USB-B Connector
1
VCC
+5VDC
2
D-
Data-
3
D+
Data+
4
GND
Ground
Table 8 Pinouts – USB Communication
Note: The user should only need to communicate to the DMM-0200 using the USB connection. The
USB connection provides full control of the DMM-0200.
