There are 2 axis of motion – X & Y
The connectors for axis X are shown in detail here.
The connectors and LEDs for Y is identical to the
X axis.
Fuse X, Y
SW1 CUR X
J10-ENC/LIM X
J11-MOTOR X
J4-SERIAL X
ENA X LED
Fuse LED
X, Y
J19-ANALOG I/O
JOYSTICK
Axis Y
J18-DIGITAL I/O
JP1 – JP8 J36-ENC OUT X/Y
USB
AC IN
Rear Panel
Axis X
Figure 4 DMM-0200 Rear View
