Technical data
General
Power supply
Ambient conditions
116
Where tolerances are given in percent and as absolute values,
the higher value applies in each case!
General
Identification .............................: The Serial No. and Article No. are located on the rating plate (nameplate) on the
back of the machine. The Article No. also specifies the equipment level of the
machine.
Weight .....................................: Cato basic machine approx. 140 kg
Cato with two Vapors and monitor approx. 180 kg
Dimensions...............................: See dimensional drawings on page 114
Power supply
Rated operating voltages ..........: depending on 100 VAC +10 %, –15 %, 50/60 Hz
power adapter 120 VAC ±10 %, 50/60 Hz
127 VAC ±10 %, 50/60 Hz
230 VAC ±10 %, 50/60 Hz
240 VAC ±10 %, 50/60 Hz
Conversion only by specially trained personnel.
Power input .............................: Max. 280 W (without auxiliary power sockets and without accessories)
Fuses .......................................: The fuses in the power adapter and master switch on contactor are only accessible
to qualified personnel with special tools.
Auxiliary power sockets (3x): 2 fuses installed per socket (2A DIN 41 622,
230/240 VAC)
Auxiliary mains sockets .............: Do not connect any HF surgery devices to the auxiliary mains sockets!
The connection of devices to the auxiliary mains socket may result in increased
risk of electric shock in the event of earthing failure!
Ambient conditions
Temperature .............................: + 15 to + 35 °C (operation)
– 20 to + 50 °C (storage / transport)
Humidity ...................................: 20 to 80 %, no condensation (operation)
0 to 98 %, no condensation (storage / transport)
Air pressure..............................: 80 to 106 kPa (operation)
50 to 110 kPa (storage / transport)
Auxiliary mains sockets
07628971
