Dräger Cato - Symbols Used

Symbol Significance
ª Pulse rate
d Defibrillator strength
< Lower alarm limit
> Upper alarm limit
_ Alarm monitoring inactive
Cursor frame in menus
z
Close menu, return to preceding menu level
E Changeover switch for standby and
measuring modes
W Cyclic activation of basic pages
Q Display standard page
G Suppress alarm tone for 2 minutes
Important note!
P Connection for equipotential bonding
Protection class type BF (EN 60601-1)
? Request for calibration
✓ Action has been completed successfully
u Action is being carried out
!!! Warning message
!! Caution message
! Advisory message
– – Alarm limit inactive
Descriptions
Symbols used
