Dräger Cato - Pulse Tone, Alarm Tone, Mode

The vertical selection area is displayed.
The menu for configuring the defaults appears with
settings:
– pulse tone for setting the volume of the pulse tone.
– alarm tone for setting the volume of the alarm tone.
– mode for changing over between adult and
neonate mode.
– parameters for setting the measuring functions.
– record for setting the list entries and printer
output.
– interfaces for setting the parameters for data
transfer.
– alarm limits for selecting the alarm limits.
– curves for selecting the curve display.
– basic config. for setting the date, time, language
and tone.
Pulse tone
The volume of the pulse tone is set here.
»0« corresponds to OFF, »1« is the lowest volume and
»9« the highest volume.
The tone is generated at the corresponding volume as it
is adjusted.
Alarm tone
The volume of the alarm tone is set here.
»1« is the lowest volume and »9« the highest volume.
The tone is generated at the corresponding volume as it
is adjusted.
Mode
This function is used to change over between adult and
neonate mode:
– adult Adult mode
– neo Neonate mode
The volumeter functions and trend displays are scaled at
the same time.
Monitor functions
Configuring monitor functions in »standby«
Changing default values
Pulse tone, Alarm tone, Mode
52
