Dräger Cato - Adjusting to the Ventilation Mode

Adjusting to the ventilation mode
For »IPPV", »MAN/SPONT« and »SIMV« ventilation
modes
The alarm limits are switched over automatically with the
change of ventilation mode.
In »IPPV« and »SIMV« modes, the »IPPV alarm limits«
alarm mode is automatically activated on the monitor if
the ventilation rate is equal to or greater than 6 breaths
per minute.
The MAN/SPONT alarm limits are automatically activated
for »MAN/SPONT« and the SIMV alarm limits for »SIMV«
mode with a ventilation frequency of less than 6 breaths
per minute.
The currently active alarm mode at any time is displayed
in the status field and flashes for the first five seconds.
The full range of alarms (»IPPV alarm limits« alarm
mode) can be reactivated by selecting IPPV mode or by
setting the ventilation frequency to a value equal to or
greater than 6 breaths per minute.
67
Monitor functions
Alarm concept
Adjusting to the ventilation mode
_
_
_
_
_
_
_
>
Alarm limits in MAN/ SIMV SIMV with fIMV ≥ 6 MAN/SPONT IPPV/SIMV
ventilation mode SPONT with fIMV < 6 and IPPV HLM HLM
Minute ventilation AMV off on on off on
off on on off on
Insp. anaesthetic gas on on on on on
off on on off on
Airway pressure Paw on on on on on
off on on off on
Exsp. CO2 concentration et CO2 on on on on on
on on on on on
Insp. CO2 concentration in CO2 on on on on on
Insp. O2 concentration FiO2 off on on off on
on on on on on
Apnoea pressure off 30 s 15 s off off
Apnoea flow off 30 s 15 s off off
Apnoea CO2 1 min. 30 s 30 s off off
Functional oxygen saturation SpO2 on on on off off
on on on off off
HR on on on off off
on on on off off
alarm activated after
