Available settings are explained as follows:
Item Description
Enable/Disable Click Enable for activating this function. If you click Disable,
this function will be closed and all the settings that you
adjusted in this page will be invalid.
Modem Settings
(for ADSL only)
Set up the DSL parameters required by your ISP. These
settings configured here are specified for ADSL only.
Multi-PVC channel - The selections displayed here are
determined by the page of Internet Access >> Multi PVCs.
Select M-PVCs Channel means no selection will be chosen.
VPI - Type in the value provided by ISP.
VCI - Type in the value provided by ISP.
Encapsulating Type - Drop down the list to choose the type
provided by ISP.
Protocol - Drop down the list to choose the one (PPPoE or
PPPoA) provided by ISP.
If you have already used Quick Start Wizard to set the
protocol, then it is not necessary for you to change any
settings in this group.
