Before you use the Vigor router, please get acquainted with the LED indicators and
connectors first.
I
I
-
-
1
1
-
-
1
1
-
-
1
1
F
F
o
o
r
r
V
V
i
i
g
g
o
o
r
r
2
2
8
8
6
6
0
0
/
/
V
V
i
i
g
g
o
o
r
r
2
2
8
8
6
6
0
0
L
L
LED Status Explanation
Blinking The router is powered on and running normally. ACT (Activity)
Off The router is powered off.
On Internet connection is ready.
Off Internet connection is not ready.
WAN2
Blinking The data is transmitting.
QoS
On The QoS function is active.
On USB device is connected and ready for use. USB1~2 / USB
Blinking The data is transmitting.
On LTE device is connected and ready for use.
Off LTE device is not detected, or has serious problem
(e.g., no SIM card, SIM pin error, SIM deactivated, and
etc.).
LTE
Blinking Slowly: LTE device is in dialing up.
Quickly: The data is transmitting.
On The router is ready to access Internet through DSL link.
DSL
Blinking Slowly: The DSL connection is ready.
Quickly: The connection is training.
WCF On The Web Content Filter is active. (It is enabled from
Firewall >> General Setup).
On The VPN tunnel is active.
Off VPN services are disabled
VPN
Blinking Traffic is passing through VPN tunnel.
On The DoS function is active. DoS
Blinking It will blink while detecting an attack.
LED on Connector
On The port is connected.
Off The port is disconnected.
Left
LED
Blinking The data is transmitting.
On The port is connected with 1000Mbps.
WAN2
(Giga)
Right
LED
Off The port is connected with 10/100Mbps
On The port is connected.
GigaL
Left
LED
Off The port is disconnected.
