Available settings are explained as follows:
Item Description
Description If required, type a brief description to explain the device
connected to VigorSwitch via the LAN port.
Shutdown Port Shutdown – The port (e.g, Port 10 in this case) which is used
to connect VigorSwitch and Vigor2860 will not be shutdown
by Vigor2860 series.
Other LAN ports of VigorSwitch allow to connect to any LAN
device. When it is checked, after clicking OK, the network
connection between that device and VigorSwitch will be
terminated.
Schedule – Two sechule profiles can be specified here to
force Vigor2860 executing specific action to VigorSwitch.
4. Click OK to save the changes and then click Send to Device. Settings will be sent to
VigorSwitch immediately.
V
V
I
I
I
I
-
-
7
7
-
-
3
3
G
G
r
r
o
o
u
u
p
p
Different switches can be classified into different group(s). Specifc password for a group can
be defined and applied to every switch uder that group.
Through the common password setting, it is not necessary for the system administrator to
remember various login passwords to access into different VigorSwitch devices.
Click any index number link to create a new switch group.
