Vigor2860 Series User’s Guide
175
If you previously have set up WAN Alias for PPPoE or Static or Dynamic IP mode in WAN2
interface, you will find them in Aux. WAN IP for your selection.
Available settings are explained as follows:
Item Description
Enable Check to enable the DMZ Host function.
Private IP Enter the private IP address of the DMZ host, or click Choose
PC to select one.
Choose PC Click this button and then a window will automatically pop
up, as depicted below. The window consists of a list of
private IP addresses of all hosts in your LAN network. Select
one private IP address in the list to be the DMZ host.
When you have selected one private IP from the above
dialog, the IP address will be shown on the screen. Click OK
to save the setting.
After finishing all the settings here, please click OK to save the configuration.
