Vigor2860 Series User’s Guide
782
type).
0 - Subnet Address
1 - Single Address
2 - Any Address
3 - Range Address
Example:
Set Subnet Address => -s u 0 192.168.1.10 255.255.255.0
Set Single Address => -s u 1 192.168.1.10
Set Any Address => -s u 2
Set Range Address => -s u 3 192.168.1.10 192.168.1.15
–d u <Address Type> <Start IP
Address> <End IP Address> |
<Address Mask>
It means to configure destination IP address including address type,
start IP address, end IP address and address mask.
u – It means “user defined”.
Address Type - Type the number (representing different address
type).
0 - Subnet Address
1 - Single Address
2 - Any Address
3 - Range Address
Example:
Set Subnet Address => -d u 0 192.168.1.10 255.255.255.0
Set Single Address => -d u 1 192.168.1.10
Set Any Address => -d u 2
Set Range Address => -d u 3 192.168.1.10 192.168.1.15
-d o:g <obj> It means to specify destination IP object and IP group.
o – indicates “object”.
g – indicates “group”
<obj>– indicates index number of object or index number of group.
Available settings range from 1-192. For example, “-d g 1" means
the first destination IP group profile.
-S o:g <obj> It means to specify Service Type object and IP group.
o – indicates “object”.
g – indicates “group”
<obj> – indicates index number of object or index number of group.
Available settings range from 1-96. For example, “-S 0 1" means the
first service type object profile.
-S u <protocol>
<source_port__value>
<destination_port_vale>
It means to configure advanced settings for Service Type, such as
protocol and port range.
u – it means “user defined”.
<protocol> – It means TCP(6),UDP(17), TCP/UDP(255).
<source_port__value> –
1 – Port OP, range is 0-3. 0:= =, 1:!=, 2:>, 3:<
3 – Port range of the Start Port Number, range is
1-65535.
5 – Port range of the End Port Number, range is 1-65535.
<destination_port_value>:
2 – Port OP, range is 0-3, 0:==, 1:!=, 2:>, 3:<
4 – Port range of the Start Port Number, range is
1-65535.
6 – Port range of the End Port Number, range is 1-65535.
-F It means the Filter action you can specify.
0 –Pass Immediately,
1 – Block Immediately,
