Available settings are explained as follows:
Item Description
Enable Choose Yes to invoke the settings for this WAN interface.
Choose No to disable the settings for this WAN interface.
Display Name Type the description for such WAN interface.
Physical Mode Choose Wireless 2.4G if you want to use wireless station
mode to access Internet. Otherwise, choose Ethernet to
access Internet through WAN2 Ethernet Port.
DSL Mode Specify the physical mode (VDSL or ADSL) for such router
manually.
Line Speed (Kbps) If your choose According to Line Speed as the Load
Balance Mode, please type the line speed for downloading
and uploading for such WAN interface. The unit is kbps.
Active Mode Choose Always On to make the WAN2 connection being
activated always.
Load Balance: Check this box to enable auto load balance
function for such WAN interface.
When the data traffic is large, the WAN interface with the
function enabled will balance the data transmission
automatically among all of the WAN interfaces in
connection status.
Failover – Choose it to make the WAN connection as a
backup connection.
WAN Failure – When the active WAN failed, such WAN
will be activated as the main network connection.
Traffic Threshold – When the data traffic of active
WAN reaches the traffic threshold (specified here),
the failover WAN will be enabled automatically to
share the overloaded data traffic.
Active When If you choose Failover as the Active Mode, Active When
will appear. Please specify which WAN will be the Backup
interface.
Any of the selected WAN disconnect – Such backup WAN
will be activated when any master WAN interface
disconnects.
All of the selected WAN disconnect – Such backup WAN will
be activated only when all master WAN interfaces
disconnect.
Check boxes for WAN1 to WAN4 – Specify the WAN
interface by checking the WAN box.
VLAN Tag insertion Such feature is offered to the user with the environment
supporting IEEE_802.1ad. In which, service is used for outer
