Set-up instructions
Operating manual 867 Version 01.0 - 12/2012 105
7.14 Lubrication
All wicks and felt bits of the upper section are soaked in oil on
delivery. This oil is conveyed to the reservoir during use. which is
why you should avoid filling too much oil during initial filling.
Figure 74: Oil level indicator
1. Pour oil through the refill opening (1) up to no more than 2 mm
below the maximum level marking (2).
Skin injuries due to contact with oil.
Oil can cause a rash if it comes into contact with the
skin.
Avoid any skin contact with the oil.
If oil gets on your skin, wash the affected skin areas
thoroughly.
WARNING
MAX
MIN
1
2
3
(1) - Refill opening
(2) - Maximum level marking
(3) - Minimum level marking
Machine damage possible due to incorrect oil level.
Too little or too much oil can cause damage to the machine.
On the first filling, only add oil up a level 2 mm below the
maximum level mark.
ATTENTION
