DURKOPP ADLER 867 Operating Manual

Set-up instructions
86 Operating manual 867 Version 01.0 - 12/2012
7.9 Fitting the oil extraction line
Figure 56: Fitting the oil extraction line
1. Fold the machine upper section back.
2. Screw the filter (2) into the oil pan with the plastic adapter to
the right.
3. Insert the tube of the oil extraction line (1) into the plastic
adapter.
1
2
(1) - Tube of the oil extraction line (2) - Filter

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
