DURKOPP ADLER 867 Operating Manual

Operating instructions
60 Operating manual 867 Version 01.0 - 12/2012
5.15 Switching switchable needle bars
On machines with switchable needle bars the needle bars can be
individually switched on and off via the L and R keys.
Figure 39: Switching switchable needle bars
Switching off a needle bar:
1. Press the key for the desired needle bar.
The key lights up. The needle bar is switched off.
Switching on a needle bar:
1. Press the illuminated key.
The key does not light up any more.
The needle bar is switched on.
You cannot switch off both needle bars at the same time. When
a needle bar is switched off and you press the key for the other
needle bar, this switches on the disabled needle bar so that both
needle bars are in use.
21
(1) - L - Key for the left needle bar
(2) - R - Key for the right needle bar

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
