DURKOPP ADLER 867 Operating Manual

Set-up instructions
Operating manual 867 Version 01.0 - 12/2012 81
7.6 Setting the working height
The working height is continuously adjustable between 750 and
900 mm (clearance between the floor and upper edge of the table
plate).
Figure 52: Setting the working height
1. Release the screws (1) on the frame bars.
2. Set the table plate to the desired height.
Important: Pull out or push in the table plate evenly at both
sides to prevent it from jamming.
3. Tighten the screws (1) on the frame bars.
1
(1) - Screws
Risk of crushing.
The table plate can sink under its own weight when
the screws on the frame bars are released. This
applies even more when the machine upper section
is already fitted.
Ensure that your hands are not jammed when
releasing the screws.
WARNING

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
