DURKOPP ADLER 867 Operating Manual

Operating instructions
28 Operating manual 867 Version 01.0 - 12/2012
5.3 Threading in the needle thread
In all machines the thread from the thread reel is fed to the
machine via the unwinding bracket.
Figure 6: Thread guide on the unwinding bracket and machine arm
1. Fit the thread reel on the thread reel holder (2).
2. Insert the thread from the rear to the front through a hole in
the guide on the unwinding bracket (1).
Risk of injury by the needle point and moving
parts.
Switch off the sewing machine before inserting the
thread.
WARNING
1
2
(1) - Guide on unwinding bracket
(2) - Thread reel holder

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
