3.4.2 Data overview by submodel
Shirt arm 1-needle machines with large hook (L)
Submodels: 867-
-160122
-190020
-190122
-190125
-190322
-190425
Sewing stitch type Double lockstitch 301
Hook type Vertical hook, large (L)
Number of needles 1
Needle system 134-35
Maximum needle strength [Nm] 130 180
Maximum sewing thread size 120/3
– 30/3
80/3 – 10/3 15/3
80/3
–10/3
15/3
Stitch length, forwards / backwards
[mm]
7 / 7 12 / 12
Adjustable stitch lengths 1 2
Maximum number of stitches 3800
Number of stitches on delivery 3400 3000 3400
Maximum fan height
(*only with reversing mechanism)
16* 20 20*
Maximum sewing foot stroke 9
Positive operating pressure [bar] 6
Air consumption [NL] 0.7
Length/width/height [mm] 690/220/460
Weight/with direct drive [kg] 55/59
Rated voltage [V/Hz] Depends on the drive package
Rated power [kVA] Depends on the drive package
