Operating instructions
56 Operating manual 867 Version 01.0 - 12/2012
5.13 Quick functions on the keypad
Depending on the submodel, the machine has a keypad on the
machine arm allowing activation of particular functions while sew-
ing.
5.13.1 Activating function keys
Figure 35: Keypad for quick functions
Activating a key function
1. Press the key.
The function is activated. The key lights up.
Deactivating a key function
1. Press the key again.
The function is deactivated. The key does not light up any
more.
+
+/–
+/–
2 4 53 6
8
1
7
(1) - Additional switch
Keys for:
(2) - Sewing backwards
(3) - Needle position
(4) - Start and end strip
(5) - Stitch length
(6) - Additional thread tension
(7) - Vertical cutter
(8) - Screws for the assignment of
the additional switch (1)
