DURKOPP ADLER 867 Operating Manual

Set-up instructions
Operating manual 867 Version 01.0 - 12/2012 83
7.7.1 Fitting the control
The DAC controllers and Efka controllers are installed according
to the same principle.
Figure 53: Fitting the control
1. Screw the control (2) onto the 4 screw holders (3) under the
table plate.
2. Clamp the power cable of the control (2) into the strain relief
mechanism (1).
3. Screw the strain relief (1) under the table plate.
3
2
1
(1) - Strain relief (2) - Control
(3) - Screw holder

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
