DURKOPP ADLER 867 Operating Manual

Operating instructions
Operating manual 867 Version 01.0 - 12/2012 23
5 Operating instructions
5.1 Switching the power supply on and off
The lower main switch (2) on the control regulates the power
supply.
Figure 2: Switching the power supply on and off
To switch on the power:
1. Press the main switch (3) down to position I.
The indicator lamps (1) and (2) light up.
To switch off the power:
1. Press the main switch (3) up to position 0.
The indicator lamps (1) and (2) go out.
+
–
4
3
2
1
(1) - Indicator lamp on the keypad
(2) - Indicator lamp on the control
(3) - Main power switch
(4) - Switch for the sewing lamp

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
