Page #65 background image
Operating instructions
Operating manual 867 Version 01.0 - 12/2012 63
To interrupt sewing:
1. Release the foot pedal in pedal position 0:
The machine stops, needles and sewing feet are down.
To continue sewing:
1. Press the foot pedal forwards to the pedal position +1:
The machine continues to sew.
To sew over thickened seams:
1. Activate the elevated sewing foot stroke using the knee lever
( Section 7.12 Sewing foot stroke).
To change the stitch length:
1. Switch on the 2nd stitch length using the key for the quick
function ( Section 7.14 Switching on the quick functions
at the keypad).
To increase the thread tension:
1. Switch on the additional tension using the key for the quick
function ( Section 7.14 Switching on the quick functions
at the keypad).
To sew intermediate strips:
1. Sewing backwards with the stitch adjustment lever
( Section 7.13 Stitch length)
or with the quick function key
( Section 7.14 Switching on the quick functions at the
keypad).
To finish a seam:
1. Press the foot pedal back completely to the pedal position -2:
The machine sews the end strip and the thread cutter cuts
the thread.
The machine stops, needles and sewing feet are up.
2. Remove the sewn material.
