Machine description
ICC424HF-CN1EN2.pdf2012-11-23
Fig. Temperature screen
The temperature screen shows the temperature of the
engine (top of display) and hydraulic fluid (bottom of
display). The values are shown in Celsius or
Fahrenheit, depending on the choice of unit system.
Fig. Asphalt temperature/Impactometer
screen
A menu for the asphalt temperature and Impactometer
value can also be shown when an accessory asphalt
temperature gauge and/or Impactometer is installed
on the machine. Further information on these
accessories are given in the Accessory Manuals.
When an engine alarm is activated, the alarm is shown
on the display.
The engine alarm is sent out from the engine ECM,
which handles the monitoring of the engine functions.
The message, which consists of an SPN and FMI
code, can be interpreted via the engine supplier error
code list.
The alarm message shown is acknowledged by
pressing the "OK" button on the display.
When a machine alarm is activated the alarm is shown
on the display, plus a warning text that describes the
alarm.
The alarm message shown is acknowledged by
pressing the "OK" button on the display.
31
