GSM network
settings for
IS-6000 Doppler
with integrated
4G/3G/2G modem
> Select network type GSM from drop-down list for communication via GSM network.
GSM
Integrated 4G/3G/2G modem:
For network settings only GSM type is needed (see below).
Note that upon delivery, the integrated 4G/3G/2G modem is already pre-configured by
the manufacturer. Just connect the dipole-antenna on the bottom of the enclosure and
insert the SIM card to automatically connect to your provider.
Note that APN, username and password are given by the network provider of the SIM Card
(network profile).
To avoid possible misconfigurations, do not change parameters. Change settings only if you
have the appropriate experience.
Modem Configuration
GSM Config
To check or change the settings of the configuration
Click Modem Configuration
The WebUI interface of the original modem manufacturer opens.
The functions are described in the following.
Note that the configuration is saved when the "Save" button is clicked, and the configuration
is applied at the next system boot.
Overview
Information regarding the cellular connectivity is displayed.
bottom left: display of current GSM connectivity
Internet
Connection
Internet IP
SIM profile
Roaming
IP address assigned by provider
Profile name
deactivated (factory setting / default setting)
WLAN AP
Connection
Router IP
Network name
Encryption
IP address network
SSID of the WiFI access point
Encryption WiFi access point
Programming
Page 80 March 2021HYB-UM-03155-EN-03
