CHAPTER 4
Basic CPI Operation
Above Ground Model 200iX/250iX Motorcycle Dynamometer Installation Guide
4-4
USING THE AIR FUEL RATIO AIR PUMP
The CPI allows control of the optional internal air pump that is part of the air fuel ratio
(AFR) sampling system. This air pump is built into the AFR module to draw exhaust
gases over the AFR sensor. The button on the control panel allows the dyno user to
turn this pump on and off. The indicator light on the control panel will illuminate
when power is provided to the pump.
If the pump does not run, check the following:
• Verify the switch on the pump assembly is on.
• Verify fuses F3 and F4 on the CPI board.
• If the E-Stop button is pressed or the external E-Stop circuit is open then the AFR
pump will not run.
Refer to the Air Fuel Ratio Module Installation and User Guide for proper operating
and maintenance procedures (P/N 98200062). Failure to follow proper procedures
may result in inaccurate data or damage to the equipment.
control panel feature description
Air Fuel Ratio Air Pump This optional accessory allows control of the internal air pump of
the air fuel ratio sampling system. Refer to page 4-4 for more
information.
Emergency Stop/Dyno Shutdown Deactivates the dyno outputs whenever the button is pressed or
the external E-Stop circuit is opened. Refer to page 4-5 for more
information.
High Pressure Blowers (Blowers) This optional accessory allows you to toggle the blowers on and
off to control the temperature of the bike. Refer to page 4-5 for
more information.
Power Carriage This accessory requires the CPI and battery to operate. The
power carriage allows you to move the bike forward and
backward by remote control to center the bike's rear tire on the
dyno drum. Refer to page 4-6 for more information.
Starter Allows for spinning up the dyno drum to bump start bikes that
may not have a starter. Refer to page 4-6 for more information.
Status Indicator Provides information on the status of the CPI control and the
various inputs to the CPI.
Wheel Clamp This optional accessory requires the CPI and battery to operate.
The wheel clamp allows for quicker loading and unloading of the
bike. Refer to page 4-7 for more information.
