CHAPTER 2
Remove the Dyno Covers
Above Ground Model 200iX/250iX Motorcycle Dynamometer Installation Guide
2-24
REMOVE THE DYNO COVERS
Before installing the iX upgrade, you will need to remove the top and side cover from
the dyno. Be sure to set the covers and screws aside; these covers will be installed later
on the iX upgrade.
1 Remove the five screws securing the top cover to the dyno and set aside. Remove
the top cover and set aside.
2 Remove the twelve screws securing the side cover to the dyno and set aside.
Remove the side cover and set aside.
Figure 2-21: Removing the Dyno Covers
