APPENDIX E
Dynamometer Specifications—Above Ground iXW Dyno
Above Ground Model 200iX/250iX Motorcycle Dynamometer Installation Guide
E-2
DYNAMOMETER SPECIFICATIONS—ABOVE GROUND IXW DYNO
The following specifications are for the above ground iXW dyno only. For iX dyno
specifications and all other dyno requirements, refer to “Dynamometer Specifications
and Requirements” on page 1-5.
CHASSIS SPECIFICATIONS
description specifications
Length
with standard carriage allow 272.00 cm (107.00 in.)
with extended carriage allow 323.00 cm (127.00 in.)
Height
to top of dyno cover 46.00 cm (18.00 in.)
Width
model 200iXW 231.00 cm (91.00 in.)
model 250iXW 305.00 cm (120.00 in.)
iXW wide drum module 124.50 cm (49.00 in.)
Weight
model 200i dyno/crated dyno 725 kg (1600 pounds)/771 kg (1700 pounds)
model 250i retarder module/crated 953 kg (2100 pounds)/1,089 kg (2400 pounds)
model iXW drum module/crated 363 kg (800 pounds)/454 kg (1000 pounds)
Drum
diameter, iXW upgrade 45.72 cm (18.00 in.)
width, iXW upgrade 55.88 cm (22.00 in.)
drum outside to drum outside 154.94 cm (61.00 in.)
Frame structural steel channel and angle
Maximum Speed 322 KPH (200 MPH)
