Extended Carriage
Version 2 Above Ground Model 200iX/250iX Motorcycle Dynamometer Installation Guide
EXTENDED CARRIAGE
Use the following instructions to install the trike carriage adapter (P/N 71300002)
and install the extended carriage assembly (P/N 78100003).
You will need the following parts:
part description part description
trike extension support
P/N 21600019
trike extension carriage
support brace assembly
P/N 61300057
screw, 5/16-UNC x 1",
button-head (5)
P/N 36500008
extended carriage assembly
includes the following:
P/N 21224114
P/N 32522100
P/N 36561045 (6)
P/N 36561670 (2)
P/N 36580434 (4)
P/N 36912100 (2)
P/N 61124871
P/N 63310901
P/N DM150-016-004
P/N DM150-016-005
P/N DM150-016-007
screw, 3/8-16-UNC x 1",
button-head (2)
P/N 36500009
trike carriage adapter
assembly
P/N 71300002
bolt, 3/8-16 x 1/2", button-
head flange, allen (7)
P/N 36580434
The following parts are included in the Trike Extension Carriage Support Brace
Assembly P/N 61300057:
leveling mount (2)
P/N 21200157
nut, 3/8-16, nylock (4)
P/N 36488100
mount
P/N 21200158
nut, 3/8-16, hex (4)
P/N DM150-011-004
