APPENDIX E
Above Ground iXW Upgrade Installation
Above Ground Model 200iX/250iX Motorcycle Dynamometer Installation Guide
E-8
INSTALLING THE ABOVE GROUND IXW DRUM MODULE
You will need the following parts:
36561045 Screw, 1/4-20 x 5/8", Ph, Torx (2)
36580404 Set Screw (2)
37620622 Woodruff Key (2)
62100010 iXW Drum Module
62200012 Driveline Assembly
1 Remove the drum safety cover from the iXW drum module.
2 Remove the eight screws securing the iXW drum top cover and set aside. Remove
the cover and set aside.
3 Remove the six screws securing the iXW drum side cover and set aside. Remove
the cover and set aside.
#
RECORD
Be sure you record the iXW drum module number on the inside cover of
this manual.
4 Place the nylon loop strap around the shaft on either side of the drum module.
5 Using a forklift, lift the drum module from the crate and place the drum module
near the dyno with the stepped end of the shaft towards the dyno. Make sure the
panels on the drum module and the dyno are parallel.
6 Remove the two existing screws from each side of the dyno frame where the
connector plates will attach.
7 Insert the woodruff key into the keyway on the iXW drum module shaft.
8 Insert the woodruff key into the keyway on the dyno shaft.
9 Slide the driveline over the key on the drum module shaft.
