1-9
SPECIFICATIONS AND OPERATING REQUIREMENTS
Dynamometer Specifications and Requirements
Version 2 Above Ground Model 200iX/250iX Motorcycle Dynamometer Installation Guide
DRILL AND DRILL BIT REQUIREMENTS
You will need to provide a drill and drill bit capable of drilling holes in concrete. Refer
to Appendix A for more information on installing Red Head Anchors.
• drill bit size: 1/2-inch
• minimum hole depth: 1 5/8-inch (41.2 mm)
ELECTRICAL REQUIREMENTS
The Model 200iX/250iX dynamometers require a 240V - 30a single-phase electrical
circuit for reliable and precise operation. No other loads should be plugged into these
circuits and these circuits should be independent of the lighting in the dyno room.
Before you plug in your dyno, you or your electrician must refer to Appendix B for
detailed information.
ENVIRONMENTAL REQUIREMENTS
FORKLIFT REQUIREMENTS
You will need to provide equipment capable of lifting a minimum of 2268 kg.
(5000 lb.) to lift the dyno off the crate and into position in your dyno room. You will
also need a pair of straps capable of supporting 2268 kg. (5000 lb.) to attach to the
dyno. Dynojet recommends using single loop style straps.
GROUND HOOK REQUIREMENTS
You may wish to install additional ground hooks (included with your dyno) for
securing the motorcycle. The tie-down loops on the dyno covers should work for most
motorcycles. If you are running motorcycles that require a different tie-down location,
mount the ground hooks accordingly.
Note: Tie-down straps MUST pull the motorcycle forward.
Using the ground hooks as a pattern, use the hardware included with the ground hook
kit to install the Red Head anchors according to the instructions in Appendix A.
description specifications
Temperature
operating min./max 10°C/50°C (50°F/122°F)
storage min./max 0°C/60°C (32°F/140°F)
Humidity 0 to 95% non condensing
