CHAPTER 2
Final Adjustments and Tests
Above Ground Model 200iX/250iX Motorcycle Dynamometer Installation Guide
2-54
HIGH PRESSURE BLOWER TEST
Test the blowers by pressing the appropriate buttons on the control panel.
POWER CARRIAGE FINAL ADJUSTMENTS AND TESTS
The power carriage is an optional accessory. To install the power carriage, refer to
“Power Carriage” on page 3-20. Refer to “Using the Power Carriage” on page 4-5 for
more information on using the power carriage. To route the power carriage cables,
refer to “Routing the Power Carriage and Wheel Clamp Cables” on page 2-38.
Using the Control Panel, press the carriage forward and backward buttons and verify
that the motor does turn.
TRIKE CARRIAGE ADAPTER ASSEMBLY TEST
1 Using the supplied chain lube or grease, lube the front and rear adapter slides
(unpainted part).
2 Pull the pin up to slide the carriage until the pin locks into the next location. Verify
the carriage slides left and right on the trike adapter plate.
WHEEL CLAMP FINAL ADJUSTMENTS AND TESTS
The wheel clamp is an optional accessory. To install the wheel clamp, refer to “Wheel
Clamp” on page 3-24. To route the wheel clamp cables, refer to “Routing the Power
Carriage and Wheel Clamp Cables” on page 2-38.
1 Place a stack of catalogs into the wheel clamp.
2 Using the Control Panel, press the close button and observe that the wheel clamp
does close. Hold the button until the motor turns off and the status light is on
steady.
3 Press and hold the right hand wheel clamp button then press the left hand button
to open the clamp.
Refer to “Using the Wheel Clamp” on page 4-6 for more information on using the
Control Panel.
