CHAPTER 1
Dynamometer Specifications and Requirements
Above Ground Model 200iX/250iX Motorcycle Dynamometer Installation Guide
1-8
COMPRESSED AIR REQUIREMENTS
You will need to provide an air hose nipple (1/4-inch NPT) to connect your clean, dry
shop air supply (60 psi, 415 kilopascal, max constant line pressure) to the
dynamometer.
The following requirements are needed when the optional air brake is included:
• regulator set to 65 psi max (450 kilopascal)
•air dryer
• shut off valve
• gauge on the regulator
• 1/4-inch NPT pipe thread connector (to attach air to the dyno)
The following requirements are needed for the on-dyno compressed air pump
assembly:
• Clean and dry air, 100 psi or greater, 5 CFM or better flow
• Fittings to hook your air system to a 3/8-inch inside diameter hose (if no air brake
is present)
• 1/4-inch NPT pipe thread compressed air connector
• optional air regulator
COMPUTER SPECIFICATIONS
You will need to provide a computer system to run the Power Core software. Refer to
www.dynojet.com for the latest computer requirements.
description minimum specifications recommended specifications
Operating System Windows 7 or later Windows 7 or later
Processor Dual Core Processor,
2GHz or faster
Intel Core i5 2.8GHz or faster
Memory 4GB System Ram 8GB System Ram or more
Hard Drive 100GB or larger
(54MB required for program)
500GB or larger
(54 MB required for program)
Monitor/Graphics Card 1280x1024 (SXGA) resolution or
higher
1600x900 (WSXGA) resolution or
higher
Network Adapter 1 free 10/100 Mbps
RJ45 Ethernet Port
1 free 10/100Mbps RJ45 Port on IP
Router, Wireless, or Wired and
Internet Access
External Media CD Rom Drive CD Rom Drive
Printer Printer, if prints or needed Color printer, if prints are needed
